260 - 2 Section Differential Car Gate Installation Guide

Contents
1. FORWARD 1
2. BEFORE STARTING INSTALLATION 1
3. JOB NUMBER IDENTIFICATION 1
4. HANDING 2
5. 2 SECTION SLIDE-UP CAR GATE ASSEMBLY 3
6. CAR GATE & RETIRING CAM INSTALLATION NOTES 5
6.1. GENERAL 5
6.2. CAR GATE RAILS & BRACES 5
6.3. CAR GATE PANEL 6
6.4. CAR GATE MOTORIZED SPROCKET OR MANUAL SPROCKETS & IDLER SPROCKETS 6
6.5. CAR GATE COUNTERWEIGHTS 6
6.6. CAR GATE CHAINS AND CHAIN STUDS 6
6.7. CAR GATE RUBBER BUMPERS 8
6.8. CAR GATE CONTACT 8
6.9. RETIRING CAM 8
6.10. PULL STRAPS 9
7. CAB / CAR ENCLOSURE PREPARATION 10
8. RAIL INSTALLATION 11
9. RAIL SPREADER & DIAGONAL BRACE 12
10. GAUGE THE RAILS 13
11. SET THE RAILS 14
12. BRACING RAILS TO CAR 15
13. COUNTERWEIGHT PARTS ASSEMBLY 16
14. COUNTERWEIGHT INSTALLATION 17
15. IDLER INSTALLATION 20
16. OPERATOR INSTALLATION 21
17. DIFFERENTIAL SPROCKET INSTALLATION 22
18. PANEL BUMPERS 23
19. UNLOADING THE PANELS 24
20. PANEL INSTALLATION 25
21. CHAIN CONNECTION DETAIL 26
22. CHAIN PATH - UPPER PANEL 27
23. CHAIN CONNECTIONS - UPPER PANEL 28
24. CHAIN PATH - LOWER PANEL 29
25. CHAIN CONNECTIONS - LOWER PANEL 30
26. CHAIN PATH - OPERATOR SPROCKET 31
27. REMOVE COUNTERWEIGHT STOP ANGLE 32
28. PULL STRAP INSTALLATION (MANUAL OPERATION) 33
29. CAR GATE / CAR GATE CONTACT 34
30. RETIRING CAM TOP ASSEMBLY 35
31. RETIRING CAM BOTTOM ASSEMBLY 36
32. RETIRING CAM ROD INSTALLATION 37
33. GOF MICRO SWITCH INSTALLATION 38
34. CAR GATE PROXIMITY SENSOR (OPTIONAL) 39
35. DOOR PROXIMITY SENSOR (OPTIONAL) 40
